Yorking | SKU: SEV-00714

Reduced by 16%

YORKING YDY 22 S3 power generator

Name: YORKING YDY 22 S3 power generator
Brand: Yorking
Price: 7839.58 EUR
Availability: InStock

€7.839,58 €9.334,28

VAT included. Shipping will be calculated at checkout.

YORKING YDY 22 S3 power generator is not in stock and will be shipped as soon as available again.

Delivery time: approx. 6 days

Collection possible from warehouse Fabrikstr. 1

Collection date after consultation

Questions to the product?

Tel.: 07622 / 6971 150

Mail: sev@sev-stromerzeuger.com

Shipping Information

Shipping costs are calculated based on the weight and the destination country. A shipping cost calculator for the entire contents of the shopping cart is available here on the product page (below the price information).

We ship up to approx. 30 kg with parcel service. We ship items with higher weight using general cargo freight forwarding or, in the case of large units, by direct transport.

Please contact us if you have special delivery requirements.

Your legal guarantee rights

LEGAL GUARANTEE Minimum two-year legal guarantee protection for goods sold in the European Union. Consumers can claim their rights under the legal guarantee of conformity, for example if goods: do not match the description; do not function as intended. Sellers are liable for any lack of conformity which existed when the goods were delivered, and which becomes apparent within the legal guarantee period. Sellers in such a situation are required to offer: free repair or free replacement; in some cases, a price reduction or full reimbursement. Some countries have a longer legal guarantee period. For second-hand goods, a shorter period may apply, but not less than one year. For more information on your rights in a specific country, scan the QR code below or ask the seller. europa.eu/youreurope/guarantees What to do if you receive non-conforming goods: 1 Contact the seller as soon as possible to report the issue; 2 Provide proof of purchase, such as a receipt, invoice, or bank statement. Sellers and producers may also offer commercial guarantees, which apply independently from the legal guarantee. For example, you may see this GARAN label representing a commercial guarantee of durability offered by the producer at no additional cost and covering the entire good.

Open the legal guarantee notice on Your Europe

Diesel · Industry · Commercial use · Backup power

YORKING YDY 28 S3

The YORKING YDY 28 S3 is a three-phase diesel generator for commercial, industrial and professional backup power applications. The water-cooled YTO Y495D diesel engine runs at 1,500 rpm and drives the YORKING Y184FS alternator. The generating set delivers 28 kVA / 22 kW maximum LTP power and 25 kVA / 20 kW PRP prime power. Power is supplied at 230/400 V at 50 Hz; an ATS connection is also provided for an optional automatic transfer switch. The stated net weight is 830 kg.

Key specifications

Maximum power

28 kVA

22 kW LTP

Prime power

25 kVA

20 kW PRP

Output voltage

230 / 400 V

Three-phase · 50 Hz

Fuel tank capacity

92 litres

Diesel

Runtime

approx. 13 h

at full load

Net weight

830 kg

Sound-attenuated version

Designed for professional use

✓

AVR voltage regulation
Automatic voltage regulation helps maintain a stable power supply to connected loads.

✓

SmartGen HGM4020
Digital controller for monitoring key engine and alternator data, with protection and alarm functions.

✓

Sound-attenuated enclosure
Enclosed design with service doors and a stated noise level of 70 dB at a distance of seven metres.

✓

Water-cooled four-cylinder engine
The YTO Y495D runs at 1,500 rpm with direct injection and mechanical speed regulation.

✓

YORKING Alternator Y184FS
Self-excited alternator with insulation class H, IP23 protection and electronic voltage regulation.

✓

ATS-ready
An ATS connection allows use with an optional automatic transfer switch.

✓

Preheating system
The integrated preheating system supports fast, reliable engine starting at low temperatures.

✓

Comprehensive safety equipment
External emergency stop, protective covers for electrical connections and lockable fuel access.

✓

Service-friendly design
Large service doors provide easy access to the engine, alternator, filters and service fluids.

✓

Easy transport
Lifting eyes on the enclosure and forklift pockets in the base frame simplify loading and positioning.

Suitable applications

Industry and manufacturing Reliable power for machinery, equipment and operational infrastructure.

Businesses and trades Stationary or temporary power for workshops, businesses and technical applications.

Professional backup power Prepared for use as a backup power solution with an appropriately sized optional automatic transfer switch.

Construction sites and projects Robust power source for long-term projects, temporary installations and remote locations.

Technical specifications

Power ratings and electrical data

PhasesThree-phase Frequency50 Hz Rated voltage230 / 400 V Maximum power28 kVA / 22 kW LTP Prime power25 kVA / 20 kW PRP Rated current36.1 A Power factorcos φ 0.8 Voltage regulationAVR ControllerSmartGen HGM4020 ATS connectionIncluded Alternator protection ratingIP23

Engine and alternator

FuelDiesel Engine manufacturerYTO Engine modelY495D Engine typeFour-stroke, four cylinders in line Engine power26 kW at 1,500 rpm Displacement2.977 litres Bore × stroke95 × 105 mm Compression ratio18:1 CoolingWater-cooled Speed regulationMechanical AspirationNaturally aspirated InjectionDirect injection Starting voltage12 V Starter power3.5 kW Battery capacity60 Ah Oil capacity8 litres Alternator manufacturerYORKING Alternator modelY184FS Alternator rated power20 kW Efficiency86.6 % ExcitationSelf-excited Insulation classH THF< 2 % Steady-state voltage regulation≤ ±1 %

Dimensions, runtime and noise

EnclosureEnclosed and sound-attenuated Dimensions L × W × H189 × 90 × 115 cm Net weight830 kg Fuel tank capacity92 litres Fuel consumption at 50 % loadapprox. 5.27 l/h Fuel consumption at 75 % loadapprox. 6.15 l/h Fuel consumption at 100 % loadapprox. 6.87 l/h Runtime at full loadapprox. 13 hours Noise level70 dB at a distance of 7 m Engine coolant capacity5 litres Coolant capacity including radiator9 litres

Included equipment and notes

Standard equipment: YORKING YDY 28 S3 with YTO Y495D diesel engine, YORKING Y184FS alternator, SmartGen HGM4020 controller, AVR voltage regulation, electric start, starter battery, preheating system, external emergency stop, protective covers for electrical connections and an enclosed, sound-attenuated housing.

Maintenance and transport: Lockable service doors, a dry air filter, fuel and oil filters, lifting eyes and forklift pockets in the base frame simplify operation, maintenance and loading.

Optional accessories: Automatic transfer switch (ATS), CMM366A-4G GSM communication module and wheel kit.

Electrical connections: The current product documentation confirms the 230/400 V output and ATS connection, but does not provide reliable information on the number of sockets or the specific Schuko/CEE socket configuration. These details are therefore not specified here.

Sizing guidance: For motors, pumps, compressors or other loads with high starting currents, the required generator capacity should be determined in advance, taking actual running loads and starting conditions into account.

Planning a professional power or backup power system?

We can help you size your generator, select a suitable automatic transfer switch and meet specific requirements for transport, installation and delivery.

Request advice 07622 / 6971 150
